NAIM SUPERLINE - SuperLine Connection Examples; 4.2 SuperLine connected to Supernait; 4.3 SuperLine connected to NAC 122 x and Flatcap 2 x

4
SuperLine Connections
4.2 SuperLine connected to Supernait
mains
input
and fuse
power
cable
direction
marker
240° 5 to 5 pin DIN
Interconnect Cables
4.3 SuperLine connected to NAC 122x and Flatcap 2x
mains
input
and fuse
power
link plug
fitted
link plug
fitted
cable
direction
marker
240° 5 to 5 pin DIN
4 pin to 5 pin DIN
(or 4 to 5 pin Hi-Line)
Interconnect Cables
