47
English
Thank you for purchasing the E3000 Ultra-Precision, High-Speed spindle system. The E3000 system was
designed for use on CNC lathes, robots, NC lathes and special purpose machines. The motor, spindle and
E
3000 CONTROLLER are designed to work as an integrated system capable of 80,000 min
-1
(rpm). This
system utilizes air to cool the motor and protect the spindle. Always use an Air Line Kit to ensur
e clean, dry,
properly regulated air is supplied to the motor and spindle. The E
3000 system is capable of being used with
coolants and cutting lubricants. Read this and all the associated component Operation Manuals carefully
before use. Always keep this Operation Manual in a place where a user can referred to for reference at any
time.
CONTENTS
IMPORTANT INSTRUCTIONS AND WARNING - Electric Devices ……………………………………………P48
1 . CAUTIONS FOR HANDLING AND OPERATION ……………………………………………………………… P49
2 . BASIC PACKAGE ……………………………………………………………………………………………………P52
3 . WARRANTY …………………………………………………………………………………………………………P53
4 . CONTACT US …………………………………………………………………………………………………………P53
5 . FEATURES ……………………………………………………………………………………………………………P53
6 . SPECIFICATIONS AND DIMENSIONS ……………………………………………………………………………P54
7 . SYSTEM CHART ……………………………………………………………………………………………………P56
8 . TORQUE CHARACTERISTICS …………………………………………………………………………………… P57
9 . CONTROL PANEL FEATURES ……………………………………………………………………………………P58
10
. REPLACING FUSES …………………………………………………………………………………………………P61
11
. BRACKET AND RUBBER PAD INSTALLATION ………………………………………………………………P62
12
. POWER CORD CONNECTION …………………………………………………………………………………… P64
13
. MOTOR CORD CONNECTION ……………………………………………………………………………………P64
14
. AIR HOSE CONNECTION …………………………………………………………………………………………P65
15
. OPERATION PROCEDURES ………………………………………………………………………………………P66
16
. EXTERNAL INPUT / OUTPUT CONNECTOR …………………………………………………………………P69
17
. PROTECT FUNCTION ………………………………………………………………………………………………P80
18
. SETTING OF OPERATING PARAMETERS ……………………………………………………………………P82
19
. BREAK IN PROCEDURE …………………………………………………………………………………………… P93
20
. TROUBLESHOOTING ………………………………………………………………………………………………P93
21
. DISPOSAL OF THE CONTROLLER ………………………………………………………………………………P95
