4
When installing the reflector,
ensure its mounting points align
with the slots on the light fixture.
When the mounting points and
slots are aligned, push the
reflector in place and rotate it in
the direction shown on the light
until you hear it click into place.
When removing the reflector,
push and hold the release
button and rotate until the
reflector is free to be removed
from the fixture.
Press the release button to
remove the reflector.
2. Installation of an Umbrella
Loosen the angle fixing knob. Put the umbrella into the
umbrella hole.
Tighten the angle fixing knob to
lock the umbrella in place.
1. Installation of the Reflector
Usage
