ENGINE SPECIFICATIONS T4.165 T4.180 T4.200
Cycle 4 strokes Diesel
Max. power - kW (hp)* 121,5 (165) 132,5 (180) 147,2 (200)
Number of cylinders / Arrangement 4 in line
Displacement (cm
3
) 2 982
Fuel timing before TDC (°) 11.8° at 3400 rpm, ECM controlled
Compression rate 17,9:1
Aspiration Turbo Intercooler
Bore x stroke (mm) 96 x 103
Maximum rpm speed at full throttle (rpm)* 3400 ± 50 rpm
Idle rpm speed (rpm)* 750 ± 50 rpm
No load rpm speed (rpm)* 4000 ± 50 rpm
Theoretical fuel consumption (l/h) 27.1 @ 3400 rpm 29.8 @ 3400 trpm 34.9 @ 3400 rpm
Weight without gearbox (kg) 330
INJECTION SYSTEM T4.165 T4.180 T4.200
Injection Direct Common Rail
Injection order 1-3-4-2
Injection pump Denso HP3
Injection pressure (bar) up tp 1800 bar, ECM controlled
LUBRICATION T4.165 T4.180 T4.200
Oil type (temperate climat) API CD-SAE 15W40
Oil pressure at idle speed (bar) 0.3
Oil pressure at max speed (bar) 2.5 to 6.1
Engine oil capacity (litre) 7.1
COOLANT T4.165 T4.180 T4.200
Coolant (litres) (50% water - 50% antifreeze) 15.5
ELECTRICAL T4.165 T4.180 T4.200
Battery capacity mini (Ah) 100-120
Alternator 12V / 100A
CONNECTIONS T4.165 T4.180 T4.200
Exhaust (mm) 90
Fuel (suction and return) (mm) 10
Seawater (mm) 38
* At engine fl ywheel, according to ISO 8665-1.
Certain specifi cations may vary according to your order
The recommended cruising speed is 200 rpm below the maximum rpm speed at full throttle
Technical characteristics
