NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 84 Programming Instructions, Volume 2
ZONE OPTIONS / ZONES 41-48 (ADDRESS 2502-2588)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 41 ► 48
Z41 Z42 Z43 Z44 Z45 Z46 Z47 Z48
1 2 3 4 5 6 7 8
Zone Area 1 (Fire) 2544
Zone Area 2 2545
Zone Area 3 2546
Zone Area 4 2547
Zone Area 5 2548
Zone Area 6 2549
Zone Area 7 2550
Zone Area 8 2551
Reserved 2552
Reserved 2553
Zone Anding Group 1 2554
Zone Anding Group 2 2555
Zone Anding Group 3 2556
Zone Anding Group 4 2557
Zone Anding Group 5 2558
Zone Anding Group 6 2559
Zone Anding Group 7 2560
Zone Anding Group 8 2561
Interior 1 Bypass 2562
Interior 2 Bypass 2563
Keypad Sounder on Alarm 2564
Ext Fire Output 1 2565
Ext Fire Output 2 2566
Ext Fire Output 3 2567
Ext Fire Output 4 2568
Ext Fire Output 5 2569
Ext Fire Output 6 2570
Ext Fire Output 7 2571
Ext Fire Output 8 2572
Reserved 2573
Reserved 2574
Carbon Monoxide 2575
Verification (Fire) 2576
Waterflow (Fire) 2577
Supervisory 2578
Monitor Zone 2579
NAC A 2580
NAC B 2581
NAC C 2582
NAC D 2583
Reserved 2584
Reserved 2585
Chime 2 2586
Delayed Trip 1 2587
Delayed Trip 2 2588
ZONE OPTIONS ADDR
ZONES 41 ► 48
Z41 Z42 Z43 Z44 Z45 Z46 Z47 Z48
1 2 3 4 5 6 7 8
Priority Zone 2502
Priority / Bypass 2503
AutoBypass 2504
Selective Bypass 2505
Keyswitch Arming 2506
AutoBypass Re-entry 2507
Pre-Alarm Warning 2508
Never Arm 2509
24-Hour Protection 2510
Burg Bell 2511
Pulse Burg Bell 2512
Burg PGM2 2513
Burg Relay 2514
Burg PGM1 2515
Exit/Entry #1 2516
Exit/Entry #2 2517
Exit/Entry Follower 2518
Auto Reset 2519
Swinger Shutdown 2520
Chime Zone 2521
Abort Delay 2522
Power-Up Delay 2523
Day Zone/Trouble Open 2524
Day Zone/Trouble Short 2525
Alarm on Day Zone/Trouble
2526
Report Alarm Tel1 2527
Rpt Alm Restore Tel1 2528
Report Trouble Tel1 2529
Rpt Tbl Restore Tel1 2530
Reserved 2531
Reserved 2532
Reserved 2533
Reserved 2534
Report Alarm Tel3 2535
Rpt Alm Restore Tel3 2536
Report Trouble Tel3 2537
Rpt Tbl Restore Tel3 2538
No EOL Resistor 2539
Sensor Watch 2540
Trouble on Open 2541
Trouble on Short 2542
Trouble on Night Open 2543
FOOTNOTES AND SYMBOLS FOR TABLES
A
2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
B
If Fire Alarm Verification is selected, then Fire must also be
selected.
C
When the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
D
Disable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.
