NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 83
ZONE OPTIONS / ZONES 33-40 (ADDRESS 2402-2488)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 33 ► 40
Z33 Z34 Z35 Z36 Z37 Z38 Z39 Z40
1 2 3 4 5 6 7 8
Zone Area 1 (Fire) 2444
Zone Area 2 2445
Zone Area 3 2446
Zone Area 4 2447
Zone Area 5 2448
Zone Area 6 2449
Zone Area 7 2450
Zone Area 8 2451
Reserved 2452
Reserved 2453
Zone Anding Group 1 2454
Zone Anding Group 2 2455
Zone Anding Group 3 2456
Zone Anding Group 4 2457
Zone Anding Group 5 2458
Zone Anding Group 6 2459
Zone Anding Group 7 2460
Zone Anding Group 8 2461
Interior 1 Bypass 2462
Interior 2 Bypass 2463
Keypad Sounder on Alarm 2464
Ext Fire Output 1 2465
Ext Fire Output 2 2466
Ext Fire Output 3 2467
Ext Fire Output 4 2468
Ext Fire Output 5 2469
Ext Fire Output 6 2470
Ext Fire Output 7 2471
Ext Fire Output 8 2472
Reserved 2473
Reserved 2474
Carbon Monoxide 2475
Verification (Fire) 2476
Waterflow (Fire) 2477
Supervisory 2478
Monitor Zone 2479
NAC A 2480
NAC B 2481
NAC C 2482
NAC D 2483
Reserved 2484
Reserved 2485
Chime 2 2486
Delayed Trip 1 2487
Delayed Trip 2 2488
ZONE OPTIONS ADDR
ZONES 33 ► 40
Z33 Z34 Z35 Z36 Z37 Z38 Z39 Z40
1 2 3 4 5 6 7 8
Priority Zone 2402
Priority / Bypass 2403
AutoBypass 2404
Selective Bypass 2405
Keyswitch Arming 2406
AutoBypass Re-entry 2407
Pre-Alarm Warning 2408
Never Arm 2409
24-Hour Protection 2410
Burg Bell 2411
Pulse Burg Bell 2412
Burg PGM2 2413
Burg Relay 2414
Burg PGM1 2415
Exit/Entry #1 2416
Exit/Entry #2 2417
Exit/Entry Follower 2418
Auto Reset 2419
Swinger Shutdown 2420
Chime Zone 2421
Abort Delay 2422
Power-Up Delay 2423
Day Zone/Trouble Open 2424
Day Zone/Trouble Short 2425
Alarm on Day Zone/Trouble
2426
Report Alarm Tel1 2427
Rpt Alm Restore Tel1 2428
Report Trouble Tel1 2429
Rpt Tbl Restore Tel1 2430
Reserved 2431
Reserved 2432
Reserved 2433
Reserved 2434
Report Alarm Tel3 2435
Rpt Alm Restore Tel3 2436
Report Trouble Tel3 2437
Rpt Tbl Restore Tel3 2438
No EOL Resistor 2439
Sensor Watch 2440
Trouble on Open 2441
Trouble on Short 2442
Trouble on Night Open 2443
FOOTNOTES AND SYMBOLS FOR TABLES
A
2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
B
If Fire Alarm Verification is selected, then Fire must also be
selected.
C
When the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
D
Disable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.
