Page #47 background imageLoading...
Page #47 background image
NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Installation Instructions, Volume 2 Page 47
Enable GEMC-FPRINT
Use when the GEMC-FPRINT module is attached to the system. The GEMC-FPRINT Parallel Printer Interface is a bus-
mounted device that allows the Gemini C-Series control panels to be connected to a parallel printer for recording system ac-
tivity. When installed on a control panel (programmed via PCD-Windows Quickloader), GEMC-FPRINT will create reports
using the same custom User, Area and Zone descriptions that have been entered into PCD-Windows Quickloader.
Enable Housing Tamper
(Required for UL Commercial Burglary; optional for all other installations)
Tamper switches protect against the opening of the control panel door or the removal of the control panel housing from the
wall or other mounting surface. Enable this feature if tamper switches are installed.
Enable H/A Keypad Display; Enable H/A Real Time Messages (see Fire Glossary)
Enable Keypad Blanking
(This option is located in the PCD-Windows Quickloader Keypad Features screen). When enabled, the GEMC-BK1 keypad
display is inhibited except when a valid code is entered.
Enable Keypad Time/ Date Display
(This option is located in the PCD-Windows Quickloader Keypad Features screen). When enabled, this option allows the
control panel internal clock be displayed on the keypad (line 2). The clock can be set by PCD-Windows Quickloader software
or from the keypad. If the clock display is enabled, and the clock is known to be incorrect (for example, after a prolonged
power outage of AC and DC), the keypads show either a blank line or a "SET TIME/DATE" message (if the option "Enable Set
Time/ Date Message" is programmed).
Enable Manager Mode Outside Overview: (This option is located in the PCD-Windows Quickloader Keypad Features screen).
When enabled, User(s) are allowed (using one keypad) to view, arm and disarm all areas for which they are authorized
(including the current area) without the need to enter Overview Mode. Press [9][*]<User Code>[ENTER] to arm all areas as-
signed to that User; press [0][*]<User Code>[ENTER] to disarm all areas assigned to that user. If any areas to be armed have
any zones in trouble, "CAN'T ARM SYSTEM/AREA # IN TROUBLE" message will be displayed.
Enable Report Test Mode Start/End
At the initiation of a test, the control panel sends a message to the central station that a test is in progress. The "Fault Find"
function (a Function Menu selection) is enabled, and normally causes all zones to give a 7-second beep at the keypad(s)
when any zone is faulted or restored. As required by SIA CP-01, Fault Find is expanded with the following features when En-
able Report Test Mode Start/End is programmed.
When Fault Find is entered, it reports to Central Station that "Test Mode" is in progress (Contact ID reports "E607"). On
completion of the report, a Ring-Back will be given.
Fault Find can not be initiated from an armed panel, and all digital dialer reporting is inhibited while in Fault Find.
Keypad will display the following warning that the system is in Fault Find: "FAULT FIND RF SIG POWER - - "
If 24-hour zone is open at end of test, no report is sent. If a 24-hour zone is tripped and not restored during Fault Find,
when the mode is exited the zone will display as "Faulted" on the keypad display.
When Fault Find is exited by pressing RESET, a Fault Find Restore Report will be sent (Contact ID reports "R607"), and
upon completion of the report a Ring-Back will be given.
Enable Report on Exit Error/Recent Close
A Recent Closing transmission is sent if an alarm occurs within two (2) minutes after the expiration of the Exit Time. If the
user number is available, it is included in the Recent Closing transmission. Note: Recent Closing transmissions are not sent
for Fire alarms.
Enable Reporting to PC Preset
This feature allows a PC computer with Quickloader Software to function as a receiver. If programmed, all alarms sent to
Telephone No. 1 will be sent to PC PRESET as well (regardless of whether or not transmissions to Telephone No. 1 were
successful). PC PRESET must be in its Standby mode for this feature to operate.
Enable Set Time/Date Message
In the event of, for example, a prolonged power outage of AC and DC, the loss of the system clock will occur and a message
"SET TIME / DATE" will be displayed on the GEMC-BK1 keypad. The message will remain until the time and date have been
re-programmed (this option is located in the PCD-Windows Quickloader Keypad Features screen).
Enable SIA FAR Exit /Entry Limits
This option is always enabled on a control panel labeled "Compliant to ANSI/SIA CP-01". Three time limits are enabled as
BURGLARY GLOSSARY
