Page 64 Installation Instructions, Volume 2
Duress Code. The panel will not allow duplicate User Codes to be programmed. Every user program code may now be
selected as an Ambush Code for Area 2-8 by entering a _5 in the Area 2-8 Options. Note: Keypad(s) must be enabled for
Ambush.
New Operation of the Panel
Cross Zoning. Required Option for cross zoning with either programmable time period or specified by manufacturer.
Default is disabled. The existing programmable by zone feature "Zone ANDing Groups" are available for the cross zoning
option required by CP-01. This feature is not enabled in the factory program. Cross Zone set time = one (1) minute.
Pre-existing feature
Swinger Shutdown. Zone will only trip once and will not restore automatically. "Auto-Reset" and "Swinger Shut-
down" (see the Zone Options tables in the programming instructions (WI1673) for specific address locations) are
disabled in order to meet the CP-01 requirement of only one alarm activation per zone during an arming period. These
features are not selected on zones 1-8 in the factory program and must not be manually enabled if they remain Fire-zones.
Auto-Reset must be programmed for all Burglary zones in a UL Installation. See the glossary entry, "Swinger Shutdown" in
this manual.
Pre-existing features
Fire Alarms. Fire Alarm Verification available option on Fire Zones. Default is disabled. The existing programmable op-
tion "Fire Alarm Verification" is available as required by CP-01. This feature is not enabled in the factory program. Note:
The GEMC-WL-SMK does not incorporate Fire Alarm Verification and thus is not compliant with ANSI/SIA-CP-01.
Pre-existing feature
Call Waiting. Disable Call Waiting on 1st Attempt. Default is disabled. When enabled, the telephone number must
be programmed with *70 in front of the telephone number. The first attempt will dial with *70 (disabling call waiting).
Subsequent attempts (if first attempt is unsuccessful) will dial without *70. Note: The digits used to disable Call
Waiting may vary with location. Be sure to confirm with local telephone company. Note: Disabling Call Waiting on
a non Call-Waiting line can result in a delay in the connection to Central Station.
7953, Option 7 (see Note 2)
(7953 ······7 ·)*
System Test. Test Mode for all zones, the sounders, and communicator. The "Fault Find" function (a Function Menu
selection) is enabled, and normally causes all hardwired zones to give a two second beep at the keypad(s) when
any zone is faulted or restored. As required by SIA CP-01, Fault Find is expanded with the following features when
Enable Report Test Mode Start/End is programmed.
• When Fault Find is entered, it reports to Central Station that "Test Mode" is in progress.
• Fault Find can not be initiated from an armed panel, and all digital dialer reporting in same area is inhibited while in
Fault Find.
• Keypad will display the following warning that the system is in Fault Find: "FAULT FIND RF SIG POWER - - "
• If a 24-hour zone is tripped and not restored during Fault Find, when the mode is exited the zone will display as
"Faulted" on the keypad display.
• When Fault Find is exited by pressing RESET, a Fault Find Restore Report will be sent.
Notes:
Note 1:
This feature is enabled in the factory program.
Note 2:
This feature is not enabled in the factory program.
Note 3:
This feature is enabled in the factory program.
Note 4:
This feature is enabled in the factory program.
• At least one Exit/Entry zone must be programmed for each Burg area. (SIA CP-01 Specification 4.2.1)
• A Gemini C-Series control panel and at least one GEMC-FK1 keypad (in a Fire-only system) or one GEMC-BK1 keypad (in a Burg-only sys-
tem), or one GEMC-FK1 and one GEMC-BK1 in a Fire/Burg combination system.
• In a Fire-only system, at least one zone expander or SLC controller or RF receiver is required.
• In a Burglary system, a GEMC-BM or GEMC-BM/PS and at least one zone expander or SLC controller or RF receiver is required.
• In addition, a minimum of one UL Listed Fire sounding device for a Fire system and a minimum one UL Listed siren for a Burglary sys-
tem is required.
• The following optional accessories support the SIA False Alarm Reduction (FAR) classification, and may be used if desired: GEMC-OUT8,
GEMC-RM3008, GEMC-EZM8, GEMC-RECV, GEMC-WL-WD2, GEMC-WL-PIR, GEMC-WL-SMK, GEMC-WL-HEAT, GEM-KEYF.
• Programming at Installation may be subordinate to other UL requirements for the intended application.
• Un-vacated premises: When the system/partition is armed, the system will arm STAY if no exit. There must be a minimum of one Stay/Away
or Delay Stay/Away zone enrolled on the partition.
• Cross zoning is not recommended for Line security Installations nor is it to be implemented on exit / entry zones.
• There is a Communication Delay of 30 seconds in this control panel. It can be removed, or it can be increased up to 45 seconds at the option
of the end user by consulting with the Installer.
• In UL installations, Entry Delay time plus Abort Delay time (total combined times) cannot exceed 60 seconds.
• Enable Exit Delay Restart must be disabled for UL Line Security/Encryption applications.
*Illustrates the LCD display for the GEMC-FK1 keypad.
7953, Option 5 (see Note 4)
(7953 ····5 ···)*
Enable Ambush Code Type in User Assignment. The Ambush Code is a separate and unique User Code. Disarm-
ing with an Ambush Code will cause a silent report to be sent to a central station. Thus, should a user be forced to
disarm, he can silently signal an emergency while appearing to be merely disarming the system. The Ambush Zone
will automatically report when programmed to report an alarm.
7953, Option 8 (see Note 2)
(7953 ·······8 )*
