NAPCO GEMINI GEMC-32 Programming Instructions

NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
NAPCO Security Group
Programming Instructions, Volume 2 Page 85
ZONE OPTIONS / ZONES 49-56 (ADDRESS 2602-2688)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 49 ► 56
Z49 Z50 Z51 Z52 Z53 Z54 Z55 Z56
1 2 3 4 5 6 7 8
Zone Area 1 (Fire) 2644
Zone Area 2 2645
Zone Area 3 2646
Zone Area 4 2647
Zone Area 5 2648
Zone Area 6 2649
Zone Area 7 2650
Zone Area 8 2651
Reserved 2652
Reserved 2653
Zone Anding Group 1 2654
Zone Anding Group 2 2655
Zone Anding Group 3 2656
Zone Anding Group 4 2657
Zone Anding Group 5 2658
Zone Anding Group 6 2659
Zone Anding Group 7 2660
Zone Anding Group 8 2661
Interior 1 Bypass 2662
Interior 2 Bypass 2663
Keypad Sounder on Alarm 2664
Ext Fire Output 1 2665
Ext Fire Output 2 2666
Ext Fire Output 3 2667
Ext Fire Output 4 2668
Ext Fire Output 5 2669
Ext Fire Output 6 2670
Ext Fire Output 7 2671
Ext Fire Output 8 2672
Reserved 2673
Reserved 2674
Carbon Monoxide 2675
Verification (Fire) 2676
Waterflow (Fire) 2677
Supervisory 2678
Monitor Zone 2679
NAC A 2680
NAC B 2681
NAC C 2682
NAC D 2683
Reserved 2684
Reserved 2685
Chime 2 2686
Delayed Trip 1 2687
Delayed Trip 2 2688
ZONE OPTIONS ADDR
ZONES 49 ► 56
Z49 Z50 Z51 Z52 Z53 Z54 Z55 Z56
1 2 3 4 5 6 7 8
Priority Zone 2602
Priority / Bypass 2603
AutoBypass 2604
Selective Bypass 2605
Keyswitch Arming 2606
AutoBypass Re-entry 2607
Pre-Alarm Warning 2608
Never Arm 2609
24-Hour Protection 2610
Burg Bell 2611
Pulse Burg Bell 2612
Burg PGM2 2613
Burg Relay 2614
Burg PGM1 2615
Exit/Entry #1 2616
Exit/Entry #2 2617
Exit/Entry Follower 2618
Auto Reset 2619
Swinger Shutdown 2620
Chime Zone 2621
Abort Delay 2622
Power-Up Delay 2623
Day Zone/Trouble Open 2624
Day Zone/Trouble Short 2625
Alarm on Day Zone/Trouble
2626
Report Alarm Tel1 2627
Rpt Alm Restore Tel1 2628
Report Trouble Tel1 2629
Rpt Tbl Restore Tel1 2630
Reserved 2631
Reserved 2632
Reserved 2633
Reserved 2634
Report Alarm Tel3 2635
Rpt Alm Restore Tel3 2636
Report Trouble Tel3 2637
Rpt Tbl Restore Tel3 2638
No EOL Resistor 2639
Sensor Watch 2640
Trouble on Open 2641
Trouble on Short 2642
Trouble on Night Open 2643
FOOTNOTES AND SYMBOLS FOR TABLES
A
2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
B
If Fire Alarm Verification is selected, then Fire must also be
selected.
C
When the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
D
Disable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.
