NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 86 Programming Instructions, Volume 2
ZONE OPTIONS / ZONES 57-64 (ADDRESS 2702-2788)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 57 ► 64
Z57 Z58 Z59 Z60 Z61 Z62 Z63 Z64
1 2 3 4 5 6 7 8
Zone Area 1 (Fire) 2744
Zone Area 2 2745
Zone Area 3 2746
Zone Area 4 2747
Zone Area 5 2748
Zone Area 6 2749
Zone Area 7 2750
Zone Area 8 2751
Reserved 2752
Reserved 2753
Zone Anding Group 1 2754
Zone Anding Group 2 2755
Zone Anding Group 3 2756
Zone Anding Group 4 2757
Zone Anding Group 5 2758
Zone Anding Group 6 2759
Zone Anding Group 7 2760
Zone Anding Group 8 2761
Interior 1 Bypass 2762
Interior 2 Bypass 2763
Keypad Sounder on Alarm 2764
Ext Fire Output 1 2765
Ext Fire Output 2 2766
Ext Fire Output 3 2767
Ext Fire Output 4 2768
Ext Fire Output 5 2769
Ext Fire Output 6 2770
Ext Fire Output 7 2771
Ext Fire Output 8 2772
Reserved 2773
Reserved 2774
Carbon Monoxide 2775
Verification (Fire) 2776
Waterflow (Fire) 2777
Supervisory 2778
Monitor Zone 2779
NAC A 2780
NAC B 2781
NAC C 2782
NAC D 2783
Reserved 2784
Reserved 2785
Chime 2 2786
Delayed Trip 1 2787
Delayed Trip 2 2788
ZONE OPTIONS ADDR
ZONES 57 ► 64
Z57 Z58 Z59 Z60 Z61 Z62 Z63 Z64
1 2 3 4 5 6 7 8
Priority Zone 2702
Priority / Bypass 2703
AutoBypass 2704
Selective Bypass 2705
Keyswitch Arming 2706
AutoBypass Re-entry 2707
Pre-Alarm Warning 2708
Never Arm 2709
24-Hour Protection 2710
Burg Bell 2711
Pulse Burg Bell 2712
Burg PGM2 2713
Burg Relay 2714
Burg PGM1 2715
Exit/Entry #1 2716
Exit/Entry #2 2717
Exit/Entry Follower 2718
Auto Reset 2719
Swinger Shutdown 2720
Chime Zone 2721
Abort Delay 2722
Power-Up Delay 2723
Day Zone/Trouble Open 2724
Day Zone/Trouble Short 2725
Alarm on Day Zone/Trouble
2726
Report Alarm Tel1 2727
Rpt Alm Restore Tel1 2728
Report Trouble Tel1 2729
Rpt Tbl Restore Tel1 2730
Reserved 2731
Reserved 2732
Reserved 2733
Reserved 2734
Report Alarm Tel3 2735
Rpt Alm Restore Tel3 2736
Report Trouble Tel3 2737
Rpt Tbl Restore Tel3 2738
No EOL Resistor 2739
Sensor Watch 2740
Trouble on Open 2741
Trouble on Short 2742
Trouble on Night Open 2743
FOOTNOTES AND SYMBOLS FOR TABLES
A
2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
B
If Fire Alarm Verification is selected, then Fire must also be
selected.
C
When the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
D
Disable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.
