Programming Instructions, Volume 2 Page 87
ZONE OPTIONS / ZONES 65-72 (ADDRESS 2802-2888)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 65 ► 72
Z65 Z66 Z67 Z68 Z69 Z70 Z71 Z72
1 2 3 4 5 6 7 8
Zone Area 1 (Fire) 2844
Zone Area 2 2845
Zone Area 3 2846
Zone Area 4 2847
Zone Area 5 2848
Zone Area 6 2849
Zone Area 7 2850
Zone Area 8 2851
Reserved 2852
Reserved 2853
Zone Anding Group 1 2854
Zone Anding Group 2 2855
Zone Anding Group 3 2856
Zone Anding Group 4 2857
Zone Anding Group 5 2858
Zone Anding Group 6 2859
Zone Anding Group 7 2860
Zone Anding Group 8 2861
Interior 1 Bypass 2862
Interior 2 Bypass 2863
Keypad Sounder on Alarm 2864
Ext Fire Output 1 2865
Ext Fire Output 2 2866
Ext Fire Output 3 2867
Ext Fire Output 4 2868
Ext Fire Output 5 2869
Ext Fire Output 6 2870
Ext Fire Output 7 2871
Ext Fire Output 8 2872
Reserved 2873
Reserved 2874
Carbon Monoxide 2875
Verification (Fire) 2876
Waterflow (Fire) 2877
Supervisory 2878
Monitor Zone 2879
NAC A 2880
NAC B 2881
NAC C 2882
NAC D 2883
Reserved 2884
Reserved 2885
Chime 2 2886
Delayed Trip 1 2887
Delayed Trip 2 2888
ZONE OPTIONS ADDR
ZONES 65 ► 72
Z65 Z66 Z67 Z68 Z69 Z70 Z71 Z72
1 2 3 4 5 6 7 8
Priority Zone 2802
Priority / Bypass 2803
AutoBypass 2804
Selective Bypass 2805
Keyswitch Arming 2806
AutoBypass Re-entry 2807
Pre-Alarm Warning 2808
Never Arm 2809
24-Hour Protection 2810
Burg Bell 2811
Pulse Burg Bell 2812
Burg PGM2 2813
Burg Relay 2814
Burg PGM1 2815
Exit/Entry #1 2816
Exit/Entry #2 2817
Exit/Entry Follower 2818
Auto Reset 2819
Swinger Shutdown 2820
Chime Zone 2821
Abort Delay 2822
Power-Up Delay 2823
Day Zone/Trouble Open 2824
Day Zone/Trouble Short 2825
Alarm on Day Zone/Trouble
2826
Report Alarm Tel1 2827
Rpt Alm Restore Tel1 2828
Report Trouble Tel1 2829
Rpt Tbl Restore Tel1 2830
Reserved 2831
Reserved 2832
Reserved 2833
Reserved 2834
Report Alarm Tel3 2835
Rpt Alm Restore Tel3 2836
Report Trouble Tel3 2837
Rpt Tbl Restore Tel3 2838
No EOL Resistor 2839
Sensor Watch 2840
Trouble on Open 2841
Trouble on Short 2842
Trouble on Night Open 2843
FOOTNOTES AND SYMBOLS FOR TABLES
A
2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
B
If Fire Alarm Verification is selected, then Fire must also be
selected.
C
When the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
D
Disable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.
