NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 2
Page 88 Programming Instructions, Volume 2
ZONE OPTIONS / ZONES 73-80 (ADDRESS 2902-2988)
ZONE OPTIONS:
1. Select the desired zone option by entering the option
number (1-8) for each selected zone.
2. Enter corresponding option number in address location, in
Binary (Bit) Format.
3. Press U to save.
NOTE: Dark shaded data value box shows option not avail-
able.
ZONE OPTIONS ADDR
ZONES 73 ► 80
Z73 Z74 Z75 Z76 Z77 Z78 Z79 Z80
1 2 3 4 5 6 7 8
Zone Area 1 (Fire) 2944
Zone Area 2 2945
Zone Area 3 2946
Zone Area 4 2947
Zone Area 5 2948
Zone Area 6 2949
Zone Area 7 2950
Zone Area 8 2951
Reserved 2952
Reserved 2953
Zone Anding Group 1 2954
Zone Anding Group 2 2955
Zone Anding Group 3 2956
Zone Anding Group 4 2957
Zone Anding Group 5 2958
Zone Anding Group 6 2959
Zone Anding Group 7 2960
Zone Anding Group 8 2961
Interior 1 Bypass 2962
Interior 2 Bypass 2963
Keypad Sounder on Alarm 2964
Ext Fire Output 1 2965
Ext Fire Output 2 2966
Ext Fire Output 3 2967
Ext Fire Output 4 2968
Ext Fire Output 5 2969
Ext Fire Output 6 2970
Ext Fire Output 7 2971
Ext Fire Output 8 2972
Reserved 2973
Reserved 2974
Carbon Monoxide 2975
Verification (Fire) 2976
Waterflow (Fire) 2977
Supervisory 2978
Monitor Zone 2979
NAC A 2980
NAC B 2981
NAC C 2982
NAC D 2983
Reserved 2984
Reserved 2985
Chime 2 2986
Delayed Trip 1 2987
Delayed Trip 2 2988
ZONE OPTIONS ADDR
ZONES 73 ► 80
Z73 Z74 Z75 Z76 Z77 Z78 Z79 Z80
1 2 3 4 5 6 7 8
Priority Zone 2902
Priority / Bypass 2903
AutoBypass 2904
Selective Bypass 2905
Keyswitch Arming 2906
AutoBypass Re-entry 2907
Pre-Alarm Warning 2908
Never Arm 2909
24-Hour Protection 2910
Burg Bell 2911
Pulse Burg Bell 2912
Burg PGM2 2913
Burg Relay 2914
Burg PGM1 2915
Exit/Entry #1 2916
Exit/Entry #2 2917
Exit/Entry Follower 2918
Auto Reset 2919
Swinger Shutdown 2920
Chime Zone 2921
Abort Delay 2922
Power-Up Delay 2923
Day Zone/Trouble Open 2924
Day Zone/Trouble Short 2925
Alarm on Day Zone/Trouble
2926
Report Alarm Tel1 2927
Rpt Alm Restore Tel1 2928
Report Trouble Tel1 2929
Rpt Tbl Restore Tel1 2930
Reserved 2931
Reserved 2932
Reserved 2933
Reserved 2934
Report Alarm Tel3 2935
Rpt Alm Restore Tel3 2936
Report Trouble Tel3 2937
Rpt Tbl Restore Tel3 2938
No EOL Resistor 2939
Sensor Watch 2940
Trouble on Open 2941
Trouble on Short 2942
Trouble on Night Open 2943
FOOTNOTES AND SYMBOLS FOR TABLES
A
2-wire smoke detectors only available for zones 1-8 or utilizing
FWC-FSLC-CZM on SLC loop. See Installation Instructions
(WI1653) for more details.
B
If Fire Alarm Verification is selected, then Fire must also be
selected.
C
When the Easy Program Menu is used, these features are
enabled by default (for new panels or after a Cold Start
(address 8179)). Zone Area 1 is enabled for the first 8 zones
only, by default.
D
Disable Auto-Reset on non-Fire zones for SIA CP-01 installa-
tions.
