NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Installation Instructions, Volume 2 Page 33
FIRE GLOSSARY
"SLC Point Supervision Failure trouble" is indicated).
Fire SLC Point Maintenance - A device on the SLC loop was powered down for maintenance or replacement, causing an
SLC loop trouble.
Fire Keypad Locked - The keypad Function Menu selection "Lock Keypad" was initiated on an unlocked GEMC-FK1 Fire
keypad.
Fire Service Mode Start - The Fire keypad (GEMC-FK1) Function Menu item "ENABLE PROGRAMMING" was initiated.
Fire Drill Start - The keypad Function Menu selection "Do Fire Drill" was initiated.
Fire Keypad Fail - A GEMC-FK1 Fire keypad is not responding (cut wire, defective keypad, etc.) and an E32 trouble indi-
cated.
Area 1 Gen. Alarm - An alarm in Area 1 was tripped, as specified by the Alarm Type selected and the Condition selected.
Zone 1 - An alarm was tripped or restored within Zone 1; a Zone 1 trouble (or trouble restore) condition was indicated; an
open or short-circuit condition for Zone 1 was indicated.
Zone 2-255 - For Zones 2 through 255, an alarm was tripped or restored within a Zone; a Zone trouble (or trouble restore)
condition was indicated; an open or short-circuit condition for a Zone was indicated.
System Low Battery - An E02 system battery trouble is generated when there is either a depleted or damaged battery and/or
the battery charging circuit is not working correctly.
AC Fail - An E01 AC power failure / brownout trouble is generated when AC power is absent from the system (or low volt-
age).
Telco Fault 1 - Enable Telephone Line 1 Fault Test will cause the panel to monitor telephone line 1. A failure will indicate
an E08 telephone line trouble. System trouble displays after a programmed delay of low on hook voltage and no off hook
line current from connected phone line.
Telco Fault 2 - Enable Telephone Line 2 Fault Test will cause the panel to monitor telephone line 2. (See "Telco Fault 1"
above).
Digital Dialer Test - This keypad Function Menu feature (TEST COMMUNICATOR) will send a programmed report code to the
central station. Note that in this case the report code received is not indicative of a system trouble, but is an indication of a
successful transmission. Should the transmission fail, the keypad will indicate an E03 communication failure (the trouble
will clear after any successful subsequent report).
RF Receiver Trouble - An trouble is generated when the wireless receiver or SLC module is not responding.
Gen. Alarm - Any alarm was tripped.
Communications Failure - An E03 communication failure trouble (system not able to report to the central station) is indi-
cated.
Relay Follows Zone (see the Burglary Glossary)
Report Telco 1
Report Telco 3 (Dual or Split Reporting)
Alarms, alarm restores, troubles and trouble restores may be selected individually for each zone. Violation of a zone selected
to report will communicate the code(s) selected for that zone to the central station.
Normally, Report Telco 1 is used to report to the central station. Report Telco 3 is used when certain zones will report to a
different receiver (split reporting); Report Telco 1 and Report Telco 3 are both used on the same zone to report to two re-
ceivers (central stations) successively (Dual Reporting). (Dual Reporting requires a successful report to Telco 1 before re-
porting to Telco 3). Also see Backup Report on Telco 2.
Note: Dual Reporting may only be used if the Central Station suppresses redundant signals (verify with your central station
before enabling).
Report Trouble See NAC Features
Report Zone Wireless Trouble/ Restore to Telco 1 (see the Burglary Glossary)
Reverse Polarity See NAC Features
RF Jam Reporting (see the Burglary Glossary)
RF Low Battery
In wireless installations, when displaying RF transmitter status, a "LoBatt" indication at the keypad denotes a low-battery
condition at the transmitter.
RF Recv High Noise
RF receiver may not receive Transmitter signals due to interference from outside signals of the same or similar frequency.
RF Recv Jam
RF receiver may not receive Transmitter signals due to high amplitude signal of the same frequency.
