NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Page 34 Installation Instructions, Volume 2
FIRE GLOSSARY
RF Receiver No response
Receiver stopped responding to polls due to malfunction, wire open or wire short.
RF-Receiver/SLC
From the System Assignment screen, RF-Receiver/SLC tab in PCD-Windows Quickloader, you can select the RF receivers
and SLC controllers used by the Gemini C-Series panel. Each address 1-4 can be set for a Receiver. Only addresses 1 and
2 can be used for SLC controllers and there cannot be any unused address before the last address used. Each SLC control-
lers can also be selected for "Class A" operation from this screen.
RF Recv Tamper
RF Receiver cover is removed or has been it is moved (back tamper).
RM3008, GEM-OUT8 or NAC Ext Supervision Trouble
The system will always enunciate RM3008, GEM-OUT8 or NAC Extender Supervision Troubles and report them to the central
station (except local systems). See also "Fire Trouble Resound".
Rotary Dialing Only See TouchTone Dialing Only
Second Call
If using the PCD-Windows Quickloader software, the Telco Answering Service can be disabled. Call the panel, hang up after
one ring by pressing the F10 key. The PCD-Windows will automatically call the panel back and the panel will answer in one
ring. See Callback-Method Download for more information.
Silence See NAC Features
Silence Auxiliary Outputs (Turn off Auxiliary Outputs)
Fire outputs can be programmed as auxiliary outputs. These auxiliary outputs should not be used for any required Fire sys-
tem operation, but should only be used for ancillary features (such as remote alarm and/or trouble annunciators not used for
evacuation sounder or required strobes). To turn off these auxiliary outputs, the GEMC-FK1 Fire keypad must be unlocked
and the option "Turn Off Aux Outputs" selected.
Smart See NAC Features
Smart Download
Smart Upload
Quick method of communications that compares the sum-checks of sections of panel program to determine if they are differ-
ent from the account sections and only communicates data that is different.
Smoke Detectors (Two Wire)
Smoke detectors can be wired to the GEMC-F8ZCPIM (see WI1651) or the FWC-FSLC-CZM Fire SLC Conventional Zone
Module (see WI1714 for the list of compatible detectors for use with the FWC-FSLC-CZM). When the Fire keypad is unlocked
and RESET is pressed, power is momentarily removed, allowing a detector latched in alarm to reset. Zones 1-8 of the
GEMC-F8ZCPIM are 2-wire smoke detector zones also suitable for use with any Normally Open Fire initiating device that
shorts on alarm (i.e. pull stations, thermal detectors and 4-Wire smoke detectors. See WI1651). Caution: Do not mix pull
stations and/or heat detectors on zones with smoke detectors using internal sounders. See table "UL Compatible Two-Wire
UL Compatible Two-Wire Smoke Detectors using GEMC-F8ZCPIM (Providing UL Recognition or Listing)
2 Wire Conventional Smoke Detectors
Manufacturer Model Base
NAPCO FW-2, FW-2R N/A
Sentrol/ESL (GE)
429C, 429CT, 511C, 511AFT, 521B/BXT, 521NB, 521NBXT, 521NCSXT,
711U-UT, 712U, 713-5U, 713-6U, 721U, 721UT, 722U
N/A
System Sensor 2W-B, 2WT-B, 2WTR-B N/A
Note: Any normally-open devices that do not require power from the control panel may be used (such as pull stations, waterflow
and thermostats), if acceptable to the authority having jurisdiction.
Important: Smoke detectors with sounders are NOT intended to replace the main fire alarm sounding device.
Maximum # per Loop
25
20
20
System Sensor 1 2WTA-B N/A
To Next Page
