Logs, see “LOG PLACEMENT” section.
Batteries, see “BATTERY
INSTALLATION” and
“BATTERY REPLACEMENT”
section.
Rating Plate, see
“RATING PLATE
INFORMATION”
section.
Media, see “Sand or Glass
MEDIA PLACEMENT” section.
Burner, see
“GAS PIPING”
section.
Grate, see “GRATE
INSTALLATION” section.
2
W415-1101 / A / 07.24.12
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 2
2.0 INTRODUCTION 3
2.1 GENERAL INSTRUCTIONS 4
2.2 GENERAL INFORMATION 5
2.3 MINIMUM HEARTH SIZE 5
2.4 RATING PLATE 5
3.0 INSTALLATION 6
3.1 BATTERY INSTALLATION 6
3.2 GAS PIPING AND BURNER PLACEMENT 6
3.3 DAMPER STOP INSTALLATION 7
4.0 FINISHING 8
4.1 SAND OR GLASS MEDIA PLACEMENT 8
4.2 GRATE INSTALLATION 8
4.3 CHARCOAL LUMPS/EMBERS 8
4.4 LOG PLACEMENT 9
4.4.1 GL22 9
4.4.2 GL28 10
4.4.3 GL32 10
4.5 MOBILE HOME INSTALLATION 11
4.6 OPTIONAL REMOTE INSTALLATION (NOT SUPPLIED) 11
5.0 WIRING DIAGRAM 12
6.0 OPERATION 13
6.1 OPERATING AND LIGHTING INSTRUCTIONS 13
7.0 ADJUSTMENTS 14
7.1 PILOT BURNER ADJUSTMENT 14
7.2 FLAME CHARACTERISTICS 14
8.0 MAINTENANCE 15
8.1 BATTERY REPLACEMENT 15
9.0 REPLACEMENTS 15
10.0 TROUBLESHOOTING 18
11.0 WARRANTY 20
12.0 SERVICE HISTORY 21
1.0 INSTALLATION OVERVIEW
To Next Page
