5.3. Introduction of PC software
PC software include 5 General Tabs: including ‘OVERALL’, ‘INFO’, ‘PARAM’,
‘CONFIG’, ‘STORAGE’.
1. OVERALL page: Basic information of BMS and PC software
✓ Manufacture name and PC software version;
✓ Communication data information: COM port, Baud rate, Data bits, Stop bits, Parity
Check;
✓ Communication status: show battery communicate with PC is OK or not.
2. INFO page --- single pack
✓ Shows 15 Cell voltage;
✓ V_SUM: module voltage;
V_AVG: average cell voltage;
V_MAX: maximum cell voltage;
V_MIN: minimum cell voltage;
V_DIFF: gap
voltage
between
V_MAX and V_MIN;
Loop count: finished cycles
Capacity_Full: fully capacity;
Capacity_Surplus: remaining capacity;
Remain_Chg_Time: remaining charging time;
Remain_Disg_Time: remaining discharging time;
Total_DSG_Capa: total discharged capacity (Ah)
CELL_TEMP1-4: 1-4 Cell sub-packs terminal temperature; PCB_TEMP: BMS
temperature;
ENV_TEMP: ambient temperature inside battery;
Current: charge/discharge current, positive current means charging, negative
current means discharging.
✓ Protect Status:
Show protection information
✓ Alarm Status:
Show alarming information
✓ Normal Status:
Show battery SOC and SOH
✓ Communication: Connect to PC software is OK or not;
✓ Communication port:
RS232: apply to single battery communication RS485:
apply to multiple batteries communication Pack_Count:
numbers of battery paralleling connection
DIP_Addr: Choose the address number same as battery accordingly
