Run LED indicator: one green LED light in front panel indicating running status.
Detailed information is shown in table 3.2.
Table 3.2. Run indicator description
LED Status
Module Condition
Flash1 (ON-0.25S, OFF-3.75S)
Register successfully, but neither charge nor
discharge
Flash2(ON-0.5S, OFF-0.5S)
Charging state
Flash3(ON-0.15S, OFF-0.15S)
Register failed
Continuous ON
Discharging state
Continuous OFF
Dormant state
Alarm LED indicator: one red LED light in front panel indicating alarms. Detailed information
is shown in table 3.3.
Table 3.3. Alarm indicator description
LED Status
Module Condition
Flash1 (ON-0.25S, OFF-3.75S)
Reserved
Flash2 (ON-0.5S, OFF-0.5S)
Faulty alarm
Flash3 (ON-0.15S, OFF-0.15S)
Reserved
Continuous ON
Failed alarm
Continuous OFF
Reserved
