Narda 26 Nardalert S3
4 Getting started
Model Information
Displays information about the monitor and rmware version as well as
sensor information.
Sensor Test
Displays individual sensor output for user to self-test system for proper
function.
Navigating sub-menu screen example
1. Tap the Button when arrow is pointing at
Alarm Indication. NS3 display changes to:
2. Tap the key again to select item to be
modied. Item is highlighted to conrm
selection.
3. Tap either the or
arrow to cycle through
choices.
4. Tap the again to select choice. Choice is
not conrmed until you “Save and Exit.”
5. Tap the arrow once to get to the “Cancel
and Exit” selection. Tap
to leave the
function without implementing the
parameter change.
6. To implement the change and to store it in
memory so the next time the unit is powered
up it will recall the setting, move the arrow
icon to the “Save and Exit” line (by tapping
twice). Tap the
key to return to the
menu selection screen.
