45
Specifi-
cations
The limit value traces in the standards exhibit
sharp edges. These limit value traces are
simulated in the ESM “RadMan” by means of
equalizer networks. The frequency response
quoted refers to the characteristic of an ideal
equalizer circuit containing only 1st order
decoupled components.
The H-field sensor should not contribute to the
measured signal at frequencies above
1 GHz, and may at most only contribute the
amount that would accrue if it were specified
up to 18 GHz. The H-field sensor may cause a
slight overestimation of the actual exposure
level in narrow frequency ranges above
1 GHz.
Specifications
