After switching on
1. The LEDs light up briefly one after another,
starting with the 12.5% LED.
A “beep” is then heard.
2. The battery charge state is indicated. One
of the four LEDs lights up.
– 100% LED means: More than 75% of
the battery capacity is available.
– 50% LED means: More than 50% of
the battery capacity is available.
– 25% LED means: More than 25% of
the battery capacity is available.
– 12.5% LED means: Less than 25% of
the battery capacity is available.
– No LED lit means: Batteries need
changing. ESM “RadMan” will soon no
longer be operational.
A “beep” is then heard.
3. The H-field sensor is activated; the E-field
sensor is inactive.
A “beep” is then heard.
4. The E-field sensor is activated; the H-field
sensor is inactive.
A double “beep” is then heard.
5. ESM-30 only:
The data recorder is configured.
A triple “beep” is then heard.
The instrument is now ready for use.
ESM “RadMan”
BN 2250/xx and BN 2251/xx
Brief operating instructions
