NARDA SignalShark 3310 - Back Panel

Slide 19© Narda Safety Test Solutions GmbH www.narda-sts.com
Back Panel
1) 3 x RF SMA(f) input
2) RF N(f) input
3) 12-pin jack for connecting the antenna
control cable
4) 10 MHz Ref SMA(f) input, 600 Ohm
SignalShark - User Interface Manual
SignalShark 3320 Device Overview
1 2 3 41 1
