Task Types
To support a wide variety of measurement applications, SignalShark provides several types of tasks:
(Scan) Spectrum Mode
› This task type supports measuring the spectrum with full frequency span of 8 kHz up to 8 GHz within one
measurement and a maximum measurement speed of 40 GHz/s.
RT Spectrum Mode
› The Real-Time Spectrum task type enables real-time spectrum measurements with a frequency span of up
to 40 MHz. This frequency span will be acquired simultaneously in frequency and also gapless in time with
3.125 µs POI.
Auto DF Mode
› The Auto Direction Finding task type supports control of the automatic DF antennas and handles the
calculation of bearings out of the DF data.
