NARVI NOVA ELECTRON Series - Prior to Installation

INSTALLATION AND INSTRUCTION MANUAL
ELECTRON 450, ELECTRON 600,
ELECTRON 800, ELECTRON 900
GB
1. ONE ELECTRIC SAUNA STOVE PACKAGE COMPRISES:
1. Stove with control equipment
2. Fixing plate + fixing screws
3. Sensing element
4. Control unit + stand
5. Sauna stove installation and instruction manual
2. PRIOR TO INSTALLATION
Perform the following checks:
- The stove is the right size (kW) for the size of the sauna (m
3
).
- Table 1 shows the sauna volumes for different stove types.
- For every 1 m
2
of uninsulated brick, tile or glass wall surface in the sauna, increase
the sauna volume by 1.5 m
3
when choosing the required stove wattage from Table 1.
The sauna volumes indicated in Table 1 are both maximum and minimum values.
Table 1. Installation data for ELECTRON stove
**) See Fig. 1 *) Use a rubber sheathed connection cable
of type H07RN-F or corresponding
Stove type Wattage Sauna Minimum safety distances for stove Amount of Connection*)
stones
Volume Height Sides Front Front From ceiling From floor 400V 3N Fuses
min max min A **) B **) C **) D **) E **)
kW m
3
m
3
cm cm cm cm cm cm kg mm
2
A
ELECTRON 450 4,5 4 7 190 5 5 2 120 5 30 5x1,5 3x10
ELECTRON 600 6 6 9 190 5 8 2 120 5 30 5x1,5 3x10
ELECTRON 800 8 8 13 190 10 10 2 120 5 30 5x2,5 3x16
ELECTRON 900 9 8 15 190 10 10 2 120 5 30 5x2,5 3x16
- Table 1 indicates both the minimum height of the sauna and the minimum safety
distances for the stove.
- Make sure the fixing plate is screwed to a solid base. Wall panelling is not solid
enough, and needs to be reinforced with either additional studs under the panel or
reinforcing boards fixed to the wall studs on top of the panel.
- The stove can also be installed in a wall recess, cf. Fig. 1.
ONLY ONE ELECTRIC STOVE TO BE INSTALLED IN A SAUNA.
