National Instruments CompactRIO sbRIO-9603 - System Architecture and Diagrams; sbRIO Block Diagrams

Block Diagrams
Figure 1. sbRIO-9603 Block Diagram
9-30 VDC
Input
Power
Selection and
Protection
On-board
Power
Supplies
sbRIO-9603
Intel Atom E3805
Dual-Core
1.33 GHz Processor
High-Speed CAN
Real-Time
Clock
Battery Holder
(1632)
RMC Connector
(240-pin 60x4 Searay)
FPGA_VIO [0-47]
Digital I/O [0-47], SE/LVDS
Digital I/O [48-95], SE/LVDS
FPGA_VIO [48-95]
CAN Port
CAN
Controller
RJ-45 TSN Gigabit
Ethernet Port
PHY
RJ-45 TSN Gigabit
Ethernet Port
PHY
USB 2.0 Device
Type-C Connector
UART
RS-232
RS-232
Console Out
XCVR
5 V
3.3 V
SATA 2.0
PCIe x1 Gen 2
USB 2.0
VBAT
LabVIEW FPGA API Data Path
Processor Data Path
NI-DAQmx API Data Path
Power Path
External Connector/Port
USB 3.1 Host
Type-C Connector
Temperature
Sensors
Watchdog
4 GB
eMMC Disk
1 GB
DDR3L
Power
Connector
2.5 V/3.3 V
Power Selector
2.5 V/3.3 V
Power Selector
Configurable per Module
NI-DAQmx
Technology
Xilinx Artix-7 75T
Optional System
Power 9-30 VDC
2x C Series
Module Interface
4 | ni.com | CompactRIO Single-Board Controller with NI-DAQmx Hardware Installation Manual
