Chapter 1 Introduction and Quick Start

The same functionality is available in victext with the vxiinreg

command. You can use

help vxiinreg for the command’s parameter

description.

You may now want to read the configuration registers from other VXI

devices in your system using the same procedure. The

InReg operation

accesses only the upper 16 KB of A16 space. Try reading the registers from

one of the devices listed in the Resource Manager Display of

vxiedit.

In this way, you can verify that your PCI-MXI-2 can access each device in

your VXI system successfully.

You can also access VXI and VME defines that are configured in A16, A24,

and A32 address spaces by using the

In and Out operations in vic or the

vxiin or vxiout commands in victext.

Default Settings

This section summarizes the hardware and software default settings for the

PCI-MXI-2 kit. If you need more information about a particular setting, or

if you want to try a different configuration, please refer to the appropriate

hardware or software chapters in this manual. The manual flowchart at the

beginning of this chapter directs you to where to find the information

you need.

PCI-MXI-2

This section summarizes the hardware and software default settings for the

PCI-MXI-2.

Table 1-1. PCI-MXI-2 Hardware Default Settings

Hardware Component Default Setting

U17 Switch 1 (FOV) OFF: PCI-MXI-2 boots off the

user-configured half of the EEPROM.

U17 Switch 2 (TST) OFF: Factory configuration of the

EEPROM is protected.

U17 Switch 3 (POS) OFF: Do not alter this setting.

U17 Switch 4 (CT) ON: Do not alter this setting.

DRAM SIMM Installed Per customer order

National Instruments MXI Series User Manual
