© National Instruments Corporation 2-1 PCI-MXI-2 for Linux
2
PCI-MXI-2 Configuration
and Installation
This chapter contains the instructions to configure and install the
PCI-MXI-2 and PCI-MXI-2 Universal module.
Caution Electrostatic discharge can damage several components on your PCI-MXI-2
module. To avoid such damage in handling the module, touch the antistatic plastic package
to a metal part of your computer chassis before removing the PCI-MXI-2 from the
package.
Configure the PCI-MXI-2
This section describes how to configure the configuration EEPROM on the
PCI-MXI-2 and PCI-MXI-2 Universal.
Figure 2-1 shows the PCI-MXI-2. The drawing shows the location and
factory-default settings on the module. Your PCI-MXI-2 may look slightly
different.
Figure 2-2 shows the PCI-MXI-2 Universal.
