Caution All connections must be made before power is
applied.
Figure 3. Powering Multiple Modules from a Single Power Supply
Red (+)
Black (–)
NI P/N 198303-XX:
Male Microfit
Y-Adapter
NI P/N 198159-XX:
Female Microfit
Pigtail
V+
V–
Any 8 - 28 V
Isolated
Power Supply
