NI Digital Waveform Generator/Analyzer Guide 26 ni.com
Table 3. NI 656x DDC Connector Pins
Pins Signal Name
Signal
Type
Signal Description
65 DDC CLK OUT
LVDS
Control Positive terminal for the exported
Sample clock.
66 DDC CLK OUT
LVDS*
Control Complementary terminal for the
LVDS exported Sample clock.
71 DDC CLK OUT
LVPECL
Control Positive terminal for the LVPECL
exported Sample clock.
72 DDC CLK OUT
LVPECL *
Control Complementary terminal for the
LVPECL exported Sample clock.
62 STROBE Control Positive external Sample clock
source which can be used for
dynamic acquisition.
63 STROBE* Control Complementary external Sample
clock source which can be used for
dynamic acquisition.
14, 17, 20, 23, 26,
29, 32, 35, 38, 41,
44, 47, 50, 53, 56,
59
DIO <0..15> Data Bidirectional digital I/O data
channels 0 through 15.
15, 18, 21, 24, 27,
30, 33, 36, 39, 42,
45, 48, 51, 54, 57,
60
DIO <0..15>* Data Complementary bidirectional
digital I/O data channels
0 through 15.
2, 5, 8 PFI <1..3> Control Positive input terminals to the
NI 656x for external triggers, or
output terminals from the NI 656x
for events.
3, 6, 9 PFI <1..3>* Control Complementary input terminals to
the NI 656x for external triggers,
or output terminals for the NI 656x
for events.
1, 4, 7, 10, 13, 16,
19, 22, 25, 28, 31,
34, 37, 40, 43, 46,
49, 52, 55, 58
GND Ground Ground reference for signals.
11, 12, 68, 69 RESERVED N/A These terminals are reserved for
future use. Do not connect to
these pins.
