Appendix A Specifications
PCI/PXI-6703/6704 User Manual A-2 www.natinst.com
Absolute accuracy...................................±1 mV max
Noise.......................................................100 µV rms, DC to 1 MHz
Power-up state ........................................Independent, user-defined values
Current Output, 6704 Only
Range ......................................................0.1 to 20.2 mA
Type ........................................................Source, does not require external
excitation source
Output impedance...................................1 GΩ min
Output compliance..................................0 to 10 V
Absolute accuracy...................................±2 µA max
Noise.......................................................1 µA rms, DC to 1 MHz
Protection................................................Short-circuit and open circuit
Power-up state ........................................Independent, user-defined values
Dynamic Characteristics
Settling time (including channel latency)
Stability
Offset temperature coefficient
Voltage ............................................5 µV/ ºC
Current (6704 only) .........................10 nA/ ºC
Accuracy Time
±0.1% 1.8 ms typ, 5.6 ms max
±0.01% 3.6 ms typ, 11.2 ms max
±0.001% 14.4 ms typ, 48.8 ms max
