© National Instruments Corporation A-1 PCI/PXI-6703/6704 User Manual
A
Specifications
This appendix lists specifications for 6703/6704 devices. These
specifications are valid for an ambient temperature of 0° to 55 °C, unless
otherwise stated.
Analog Output
Number of voltage channels .................. 16
Number of current channels
for the 6704 ............................................ 16
Resolution .............................................. 16-bit
Recommended warm-up time ................ 15 minutes
Transfer Characteristics
INL ......................................................... ±1 LSB max
DNL ....................................................... ±1 LSB max
Monotonicity.......................................... 16 bits, guaranteed
Voltage Output
Range ..................................................... ±10.1 V
Output coupling...................................... DC
Output impedance .................................. 0.1 Ω max
Current drive .......................................... ±10 mA max
Load capacitance.................................... 10,000 pF max
Protection ............................................... Short-circuit to ground
