A-8 | ni.com
Appendix A Specifications
PCIe-8361 (199042A/B/C-01L)
Note These specifications are typical at 25 °C, unless otherwise stated, and are
subject to change without notice.
Physical
Dimensions 6.7 cm × 7.1 cm (2.6 in. × 2.8 in.)
Maximum cable length 7 m
Slot requirements One slot (PCI Express, standard height or low
profile)
Compatibility Fully compatible with the PCI Express
Specification, Revision 1.0a
Weight 0.04 kg (0.08 lb) typical
Power Requirements
Environment
Maximum altitude 2,000 m
Pollution Degree 2
Indoor use only.
Operating Environment
Ambient temperature range 0 to 55 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)
Relative humidity range 10 to 90%, noncondensing
(Tested in accordance with IEC 60068-2-56.)
Power Rail Typical Current Maximum Current
+3.3 V 360 mA 450 mA
+3.3 VAux 1 mA 10 mA
+12 V 0 A 0 A
