© National Instruments Corporation | A-25
MXI-Express x1 Series User Manual
Slot Type Compatibility
Physical
Dimensions 10.0 cm × 16.0 cm (3.9 in. × 6.3 in.)
Maximum cable length 200 m (Fiber-Optic)
Slot requirements One PXI or PXI hybrid peripheral slot
Compatibility Fully compatible with the PXI Hardware
Specification, Revision 2.1
Weight 0.14 kg (0.31 lb) typical
LED Status Descriptions
PXI PXI-8336
*
— 
*
*
The PXI-8336 is part of the MXI-4 family of products and has the same cable connector as the
PCI-8366, PXI-8366, and PXI-8367, but will only function when connected in valid cases as shown.
PXI Chassis PXI Express Chassis
NI PXI Board
Controller
Peripheral
Controller Peripheral
Hybrid
PXI-8367 —  — — 
LED Color Meaning
PWR/LINK Off Power is off
Blinking Red Power is out of spec
Solid Amber Power is within spec; no link to chassis
Solid Green Power is within spec; link established
From Chassis Targets
H
