© National Instruments Corporation | A-29
MXI-Express x1 Series User Manual
Slot requirements One PXI controller slot
Compatibility Fully compatible with the PXI Hardware
Specification, Revision 1.0
Weight 0.25 kg (0.55 lb) typical
Power Requirements
Environment
Maximum altitude 2,000 m
Pollution Degree 2
Indoor use only.
Operating Environment
Ambient temperature range 0 to 55 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)
Operating relative humidity 10 to 90%, noncondensing
(Tested in accordance with IEC 60068-2-56.)
Storage Environment
Ambient temperature range -40 to 70 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)
Relative humidity range 5 to 95%, noncondensing
(Tested in accordance with IEC 60068-2-56.)
Power Rail Typical Current Maximum Current
+3.3 V 775 mA 1.25 A
+5 V 5 mA 20 mA
+12 V 200 mA 350 mA
-12 V 0 A 0 A
