© National Instruments Corporation | A-35
MXI-Express x1 Series User Manual
PXIe-8364 (193970x-01L)
Note These specifications are typical at 25 °C, unless otherwise stated, and are
subject to change without notice.
Physical
Dimensions 10.0 cm × 16.0 cm (3.9 in. × 6.3 in.)
Maximum cable length 7 m
Slot requirements One peripheral slot (PXI Express or
CompactPCI Express)
Compatibility Fully compatible with the PXI Express
Hardware Specification, Revision 1.0 and the
PICMG CompactPCI Express EXP.0 R1.0
Specification
Weight 0.15 kg (0.33 lb) typical
Power Requirements
Environment
Maximum altitude 2,000 m
Pollution Degree 2
Indoor use only.
Operating Environment
Ambient temperature range 0 to 55 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2. Meets MIL-PRF-28800F
Class 3 low temperature limit and
Power Rail Typical Current Maximum Current
+3.3 V 480 mA 700 mA
+12 V 430 mA 750 mA
+5 VAux 5 mA 20 mA
