National Instruments PCI-8361 User Manual

© National Instruments Corporation | B-15
MXI-Express x1 Series User Manual
PXI-8366 (199991x-03L)
Note These specifications are typical at 25 °C, unless otherwise stated, and are
subject to change without notice.
Functional Block Diagram
Figure B-3. PXI-8366 (199991x-03L) Block Diagram
Connectivity Support From a Host PC
From Host Targets
Slot Type Product
PXI Chassis
PXI-8366 PXI-8336
*
PCI PCI-8366  —
PCI PCI-8336
*
— 
*
*
The PCI-8336 and PXI-8336 are part of the MXI-4 family of products and have the same cable
connectors as the PCI-8366, PXI-8366, and PXI-8367, but will only function when connected in the
valid case as shown.
PCIe-to-PCI
Bridge
PCI
MXI-Express x1
Fiber Optic
PCIe Gen 1 x1

National Instruments PCI-8361 Specifications

General

Brand	National Instruments
Model	PCI-8361
Category	PCI Card
Language	English
