Foundation Fieldbus Hardware and NI-FBUS Software Installation Guide | © National Instruments | 5

Figure 3. Connecting the USB-8486 to a Desktop PC

Figure 4. Connecting the USB-8486 to a Laptop PC

1 Desktop PC 2USB-8486 3 DB-9 Connector

1 Portable Computer 2 USB Port 3USB-8486 4 DB-9 Connector
