Appendix A Specifications
© National Instruments Corporation A-11 NI PXI-1042 Series User Manual
Figure A-3 shows the PXI-1042 Series chassis rack mount kit components.
Figure A-3. PXI-1042 Series Chassis Rack Mount Kit Components
1 Front Rack Mount Kit 2 PXI-1042 Series Chassis 3 Optional Rear Rack Mount Kit
1
2
3
NI PXI-1042
