NI PXI-4130 Calibration Procedure | © National Instruments | 37
Table 20. NI 4130 Output Parameters and Test Limits for Current Programming
Accuracy Adjustment
Channel
Current
Limit
Range
Voltag e
Level
Range
Voltag e
Level
Iteration Output
0 1A 6V 6V 1 20 mA
2 350 mA
3 700 mA
1 200 μA 20 V 20 V 1 2.00 μA
2 24.0 μA
3 46.0 μA
4 68.0 μA
5 90.0 μA
6 112 μA
7 134 μA
8 156 μA
9 178 μA
10 200 μA
-20 V 11 2.00 μA
12 24.0 μA
13 46.0 μA
14 68.0 μA
15 90.0 μA
16 112 μA
17 134 μA
18 156 μA
19 178 μA
20 200 μA
