38 | ni.com | NI PXI-4130 Calibration Procedure
1 2mA 20 V 20 V 1 20.0 μA
2 0.240 mA
3 0.460 mA
4 0.680 mA
5 0.900 mA
6 1.12 mA
7 1.34 mA
8 1.56 mA
9 1.78 mA
10 2.00 mA
-20 V 11 20.0 μA
12 0.240 mA
13 0.460 mA
14 0.680 mA
15 0.900 mA
16 1.12 mA
17 1.34 mA
18 1.56 mA
19 1.78 mA
20 2.00 mA
20 mA 20 V 1 0.200 mA
2 2.40 mA
3 4.60 mA
Table 20. NI 4130 Output Parameters and Test Limits for Current Programming
Accuracy Adjustment (Continued)
Channel
Current
Limit
Range
Voltag e
Level
Range
Voltag e
Level
Iteration Output
