NI PXI-5650/5651/5652 Calibration Procedure | © National Instruments | 3
Test Equipment
Table 2 lists the equipment required to calibrate the PXI-5650/5651/5652. If you do not have the
recommended equipment, select a substitute calibration standard using the specifications listed
in Table 2.
Table 2. Required Equipment Specifications for
PXI-5650/5651/5652 Calibration
Required
Equipment
Recommended
Model
Where Used
Minimum
Requirements
Spectrum
analyzer
Rohde & Schwarz
(R&S) FSU
Spectrum Analyzer
with Preamplifier
(option B23 and
B25)
Characterizing the
spectrum analyzer
Frequency
accuracy
Low power level
accuracy
Single sideband
phase noise
Harmonics
Subharmonics
Nonharmonics
Frequency range:
500 kHz to 13.2 GHz
Noise floor:
<-150 dBm/Hz
6 dB precision
attenuator
Anritsu 41KB-6 Characterizing the
spectrum analyzer
Frequency
accuracy
Low power level
accuracy
Single sideband
phase noise
Harmonics
Subharmonics
Nonharmonics
Frequency range:
500 kHz to 6.6 GHz
Power rating: 2 W
Impedance: 50 Ω
VSWR: ≤1.1:1
Power meter Anritsu ML2438A
with an Anritsu
SC7400 thermal
sensor
Characterizing the
spectrum analyzer
High power level
accuracy
Range: -55 dBm to
20 dBm
Frequency range:
100 kHz to 18 GHz
