6 | ni.com | NI PXI-5650/5651/5652 Calibration Procedure
Figure 1 shows the programming flow for a complete calibration.
Figure 1. Complete Calibration Programming Flow
Initial Setup
Refer to the NI PXI-5650/5651/5652 Getting Started Guide for information about how to install
the software and hardware and how to configure the device in MAX.
Characterizing the Test System
The following procedures characterize the test equipment used during verification and
adjustment.
Caution The connectors on the device under test (DUT) and test equipment are
fragile. Carefully perform the steps in these procedures to prevent damaging any
DUTs or test equipment.
Characterizing the Spectrum Analyzer
Complete the following steps to characterize the spectrum analyzer:
1. Connect the PXI-5650/5651/5652 REF IN/OUT front panel connector to the rubidium
10 MHz frequency reference signal using the SMA (m)-to-BNC (m) cable.
Document
Post-Adjustment
Results
Document
Pre-Adjustment
Results
Calibration/
Verification
Complete
Ye s No
Verify
Meets
Calibration
Te st Limits?
Review Verification/
Adjustment Procedure
or Return Device
Adjust (Calibration Dates
and Temperatures Updated)
Verify
To Next Page
