CLK IN
SMB
Imports an external Reference Clock or Sample Clock to the
device
CLK OUT Exports the Reference Clock from the device
PFI 0 PFI line for digital trigger input/output
PFI 1 PFI line for digital trigger input/output and probe
compensation; no subsample trigger accuracy
Configuring the PXIe-5160/5162 in MAX
Use Measurement & Automation Explorer (MAX) to configure your NI hardware. MAX
informs other programs about which NI hardware products are in the system and how they are
configured. MAX is automatically installed with NI-SCOPE.
1. Launch MAX.
2. In the configuration tree, expand Devices and Interfaces to see the list of installed NI
hardware.
Installed modules appear under the name of their associated chassis.
3. Expand your Chassis tree item.
MAX lists all modules installed in the chassis. Your default names may vary.
Note If you do not see your module listed, press <F5> to refresh the list of
installed modules. If the module is still not listed, power off the system, ensure
the module is correctly installed, and restart.
4. Record the identifier MAX assigns to the hardware. Use this identifier when
programming the PXIe-5160/5162.
5. Self-test the hardware by selecting the item in the configuration tree and clicking Self-
Test in the MAX toolbar.
The MAX self-test performs a basic verification of hardware resources.
8 | ni.com | PXIe-5160/5162 Getting Started Guide
