National Instruments PXIe-6570 User Manual

Category Supported Opcodes
Flow Control
• repeat
• jump
• jump_if
• set_loop
• end_loop
• exit_loop
• exit_loop_if
• call
• return
• keep_alive
• match
• halt
Sequencer Flags and Registers
• set_seqflag
• clear_seqflag
• write_reg
Signal
• set_signal
• pulse_signal
• clear_signal
Digital Source and Capture
• capture_start
• capture
• capture_stop
• source_start
• source
Pipeline Latencies
Minimum delay between source_start
opcode and the first source opcode or
subsequent source_start opcode
3 μs
Matched and failed condition pipeline
latency
80 cycles
PXIe-6570 Specifications | © National Instruments | 11
