National Instruments PXIe-6570 User Manual

Current levels
Range 1.5 mA to 24 mA
Resolution 488 nA
Accuracy 1 mA, 3 V over/under drive, typical
PPMU
PPMU Force Voltage
Signal type Single-ended, referenced to the DGS pin when
connected. Otherwise referenced to GND.
Voltage levels
Range -2 V to 6 V
Resolution 122 μV
Accuracy ±15 mV, 1 MΩ load, warranted
PPMU Measure Voltage
Signal type Single-ended, referenced to the DGS pin when
connected. Otherwise referenced to GND.
Voltage levels
Range -2 V to 6 V
Resolution 228 μV
Accuracy ±5 mV, warranted
PPMU Force Current
Table 1. PPMU Force Current Accuracy
Range Resolution Accuracy
±2 µA 60 pA ±1% of range for Zone 1 of Figure 2. on page 8, warranted
±32 µA 980 pA
±128 μA 3.9 nA
±2 mA 60 nA
±32 mA 980 nA
PXIe-6570 Specifications | © National Instruments | 7
