National Instruments PXIe-6570 User Manual

General
Channel count 32
Multi-site resources per instrument 8
System channel count
1
256
Large Vector Memory (LVM) 128M vectors
History RAM (HRAM) 1,023 cycles
Maximum allowable offset
2
(DGS minus GND)
±300 mV
Supported measurement range -2 V to 6 V
Timing
Vector Timing
Maximum vector rate 100 MHz
Vector period range 10 ns to 40 µs (100 MHz to 25 kHz)
Vector period resolution 38 fs
Timing control
Vector period Vector-by-vector on the fly
Edge timing Per channel, vector-by-vector on the fly
Drive formats Per channel, vector-by-vector on the fly
Clock Generation
Master clock source PXIe_CLK100
3
Clock domains One (independent clock domains on a single
instrument not supported)
1
The system channel count is the maximum number of channels available when using multiple
PXIe-6570 instruments in a single chassis as a digital subsystem. Some functionality described in
this document requires that a PXIe-6674T synchronization module be used in conjunction with
each digital subsystem.
2
If the total voltage sourced or driven on any pin relative to GND exceeds the supported
measurement range, instrument performance may be degraded.
3
Sourced from chassis 100 MHz backplane reference clock, external 10 MHz reference, or
PXIe-6674T.
PXIe-6570 Specifications | © National Instruments | 3

National Instruments PXIe-6570 Specifications

General

Brand	National Instruments
Model	PXIe-6570
Category	Industrial Electrical
Language	English
