Figure 10. Replacing the PXIe-8822/42 M.2 Hard Drive (PXIe-8822 Shown)
1
4
2
3
1. M.2 Heat Spreader Phillips Screws
2. M.2 Heat Spreader
3. M.2 Hard Drive
4.
M.2 Hard Drive Phillips Screw
© National Instruments
31
PXIe-8822/42/62 Getting Started
