National Instruments PXIe-8862 - Front Panel Features and LEDs

Peripheral External Connector Description
Video (DisplayPort 1.4) DisplayPort Intel HD Graphics
Thunderbolt 4 USB Type C (2 ports) Thunderbolt 4 compliant,
supports USB, PCI Express, and
DisplayPort
Serial COM1 (9-pin DSUB) RS-232 serial port
Ethernet Port 0 LAN (RJ45) 10M/100M/1000M/2.5G
Ethernet connection
Intel I225
Wake on LAN supported
Ethernet Port 1 LAN (RJ45) 10M/100M/1000M/2.5G
Ethernet connection
Intel I225
Wake on LAN supported
USB 2.0 USB 4-pin Series A stacked
receptacle (4 ports)
Hi-Speed USB 2.0
USB 3.2 Gen 1 USB 9-pin Series A stacked
receptacle (2 ports)
SuperSpeed USB, backwards
compatible with USB 2.0
PXI trigger Trigger (SMB) Routing PXI triggers to or from
the backplane trigger bus
GPIB GPIB (25-pin Micro D) General-Purpose Interface Bus,
IEEE 488.2
Front Panel Features
The PXIe-8822/42/62 has two front panel LEDs that show PC status and two user
LEDs:
■
DRIVE LED—Indicates when an access to the internal drive is occurring.
■
PWR OK/FAULT LED—Indicates the controller status. The LED indicates one
of the following states:
