2. RS-232 Serial
3. DisplayPort 1.4
4.
Ethernet
5. Thunderbolt 4
6.
USB 2.0
7. USB 3.2
8.
Trigger
9.
Reset Button
10.
LEDs
Figure 5. PXIe-8862 Front Panel Layout
2
3
5
1
4
8
9
10
11
6
7
1. GPIB
2.
RS-232 Serial
3.
DisplayPort 1.4
4. Ethernet
5. Thunderbolt 4
6.
USB 2.0
7.
DisplayPort 1.4
8.
USB 3.2
9.
Trigger
10.
Reset Button
