SCXI-1353 Shielded Cable Assembly 2 ni.com
❑ 100-pin E Series DAQ device
❑ Two SCXI modules
Note Refer to the Connections and Pin Assignments section for the SCXI modules that
you can use with each 100-pin E Series DAQ device.
❑ Computer
❑ Four small screws (included in this kit)
❑ Two cable tie wraps
❑ SCXI-1353 Shielded Cable Installation Guide
❑ Small Phillips screwdriver
❑ Small flat-blade screwdriver
Conventions
The following conventions are used in this guide:
bold Bold text denotes items that you must select or click on in the software,
such as menu items and dialog box options. Bold text also denotes
parameter names.
This icon denotes a note, which alerts you to important information.
italic Italic text denotes variables, emphasis, a cross reference, or an introduction
to a key concept. This font also denotes text that is a placeholder for a word
or value that you must supply.
monospace Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames and extensions, and code excerpts.
