© National Instruments Corporation 9 SCXI-1353 Shielded Cable Assembly
Using the SCXI-1353 with an NI 6031E, NI 6033E, NI 6061E, or NI 6071E
The MIO-16 cable connects the MIO-16 portion of the AT-MIO-64E-3
pinout to the SCXI-1349. The EXTENDED I/O cable connects the
remainder of the AT-MIO-64E-3 pinout to the AI-48/DIO-24.
You can connect the MIO-16 cable, using the SCXI-1349, to the following
SCXI modules: SCXI-1100, SCXI-1120, SCXI-1121, SCXI-1122,
SCXI-1124, SCXI-1140, SCXI-1141, SCXI-1160, SCXI-1161,
SCXI-1162, SCXI-1162HV, SCXI-1163, SCXI-1163R, SCXI-1180,
or SCXI-1181.
ACH47 GND 84 34 18
ACH48 PA6 85 35 17
ACH56 GND 86 36 51
ACH49 PA5 87 37 16
ACH57 GND 88 38 50
ACH50 PA4 89 39 49
ACH58 GND 90 40 15
ACH51 PA3 91 41 14
ACH59 GND 92 42 48
ACH52 PA2 93 43 13
ACH60 GND 94 44 47
ACH53 PA1 95 45 46
ACH61 GND 96 46 12
ACH54 PA0 97 47 11
ACH62 GND 98 48 45
ACH55 +5V 99 49 10
ACH63 GND 100 50 44
Pins 1 through 9 and pins 35 through 43 on the 68-pin connector are not connected.
Table 2. Extended I/O Cable Connections (Continued)
Signal Names Connector Pin Numbers
NI 6031E, NI 6033E,
NI 6061E, NI 6071E
NI 6021E, NI 6025E 100-Pin 50-Pin 68-Pin

National Instruments SCXI-1353 Specifications

General

Brand	National Instruments
Model	SCXI-1353
Category	Cables and connectors
Language	English
